Folding portable solar panel kits are perfect for camping, caravanning, 4X4 and the use as a backup or emergency power source when the grid fails! The simple design makes set up easy and hassle free. The kits takes less than 2 minutes to set up. Position in a sunny location pointing north and connect your 4X4 or caravan battery (or any other 12volt DC battery) and you have immediate charging capability.
Kit Specifications
Solar Panels: 2 x 100W.
Folded Dimensions: 1000mm x 700mm x 75mm.
Weight: 20.5kg.
Max-power: 200W.
Max-power Voltage: 18.0V.
Max-power Current: 2 x 5.65A.
Open-circuit Voltage: 23.30V.
Short-circuit Current: 2 x 5.95A.
Kit Contents
High performance polycrystalline solar cells.
Adjustable support legs – to change inclination of the solar panels for direct sun exposure.
Sturdy aluminium frame, tempered glass, with polymer protection corners.
5m of 2.5mm cable with eyelets and Anderson plug (50A).
Bag Not Included in 200W Kit.
IP20 rated Victron PWM charge controller: 20A.
